For lighting installations
- Fits many different luminaires
- LED drivers with various functions can be used
- Possibility to route multiple control channels inside the LED Profile
- Optional cover to create elegant and seamless installations
A flexible system of aluminium profiles for display lighting.
The profiles comes in two variants:
Low and High.
- Impact resistant matte painted surface
- Sold per meter, max 3000 mm
- A range of different lighting fixtures may be mounted on the profiles.
In the luminare range you'll find Arty series, Dinkey, Gizmo series and Gimmick.
Technical specification
- Material
- Profiles of extruded aluminium
- End caps of polypropylene
- Finish
- Grey (RAL 7040)
- Black (RAL 9005)
- White (RAL 9016)
- Length
3000 mm
- Mounting
Screw, mounting clips
LED Profile Low
Fits all luminaires from the CCL (Constant Current LED profile) range
Color | Art. no | Name | Dimensions (HxWxL) | Colour |
---|---|---|---|---|
LPL-1 | LED Profile Low, Grey | 10*17 mm, max 3000 mm, Cover not included | Grey | |
LPL-2 | LED Profile Low, Black | 10*17 mm, max 3000 mm, Cover not included | Black | |
LPL-3 | LED Profile Low, White | 10*17 mm, max 3000 mm, Cover not included | White |
LED Profile High
Fits all luminaires from the CCL (Constant Current LED profile) range
Color | Art. no | Name | Dimensions (HxWxL) | Colour |
---|---|---|---|---|
LPH-1 | LED Profile High, Grey | 17*17 mm, max 3000 mm, Cover not included | Grey | |
LPH-2 | LED Profile High, Black | 17*17 mm, max 3000 mm, Cover not included | Black | |
LPH-3 | LED Profile High, White | 17*17 mm, max 3000 mm, Cover not included | White |
Cover
Fits LED Profile High and Low
Color | Art. no | Name | Dimensions (HxWxL) | Colour |
---|---|---|---|---|
LPC-1 | Cover for LED Profile, Grey | 3*16 mm, max 3000 mm | Grey | |
LPC-2 | Cover for LED Profile, Black | 3*16 mm, max 3000 mm | Black | |
LPC-3 | Cover for LED Profile, White | 3*16 mm, max 3000 mm | White |
Clips
- Mounting-clips for LED Profiles
Color | Art. no | Name | Dimensions | Colour |
---|---|---|---|---|
LFH-12-1 | Mounting clips for LED Profile High, incl. screws | 17x17mm | Grey | |
LFH-12-2 | Mounting clips for LED Profile High, incl. screws | 17x17mm | Black | |
LFH-12-3 | Mounting clips for LED Profile High, incl. screws | 17x17mm | White | |
LFL-12-1 | Mounting clips for LED Profile Low, incl. screws | 17x17mm | Grey | |
LFL-12-2 | Mounting clips for LED Profile Low, incl. screws | 17x17mm | Black | |
LFL-12-3 | Mounting clips for LED Profile Low, incl. screws | 17x17mm | White |
End caps
Color | Art. no | Name | Colour |
---|---|---|---|
PT-41-1 | End Cap Profile Low | Grey | |
PT-41-2 | End Cap Profile Low | Black | |
PT-41-3 | End Cap Profile Low | White | |
GIZ-A512B-1 | End Cap Profile High | Grey | |
GIZ-A512B-2 | End Cap Profile High | Black | |
GIZ-A512B-3 | End Cap Profile High | White |
Connector cables
- Connector cables are used to link CCL-fixtures
- The last fixture in the line needs a LED Terminator to short the circuit
Color | Art.no | Benämning | Specifikation |
---|---|---|---|
GIZ-KM-5 | LED Connector Cable 50mm | Plug Female/Female | |
GIZ-KM-10 | LED Connector Cable 100mm | Plug Female/Female | |
GIZ-KM-15 | LED Connector Cable 150mm | Plug Female/Female | |
GIZ-KM-25 | LED Connector Cable 250mm | Plug Female/Female | |
GIZ-KM-35 | LED Connector Cable 350mm | Plug Female/Female | |
GIZ-KM-65 | LED Connector Cable 650mm | Plug Female/Female | |
GIZ-KM-105 | LED Connector Cable 1050mm | Plug Female/Female | |
GIZ-KS-100 | LED Extension Cable 1000mm | Plug Male/Female | |
GIZ-KA-20 | LED First Connector 200mm | Plug Female | |
GIZ-KT-P | LED Terminator | Plug |
LED Distributor
Distribution blocks. Unused slots needs to be filled with a LED Terminator.
Art.no | Benämning | Specifikation |
---|---|---|
GIZ-B3 | LED 3-Distributor | 1 in 3 out |
GIZ-B6 | LED 6-Distributor | 1 in 6 out |
LED Cable
- Decorative cable for Constant Current.
- Swedish-made cable developed by Ljusdesign
Color | Art.no | Benämning | Specifikation |
---|---|---|---|
GIZ-KA-3000-1 | LED First Connector 3000mm | Grey | |
GIZ-KA-3000-2 | LED First Connector 3000mm | Black | |
GIZ-KA-3000-3 | LED First Connector 3000mm | White | |
GIZ-KL-1 | LED cable, Grey | Ø2,9mm 2*0,14, Zero Halogen / meter | |
GIZ-KL-2 | LED cable, Black | Ø2,9mm 2*0,14, Zero Halogen / meter | |
GIZ-KL-3 | LED cable, White | Ø2,9mm 2*0,14, Zero Halogen / meter |
Gizmo CC / LED PROFILE
- For installation on LED profile High or Low. Max 700mA.
- Dimmable via constant current LED driver.
Light temperature | Color | Art.no | Name | Specification | Color |
---|---|---|---|---|---|
GIZ22-CCL-1 | Gizmo CC/700mA LED profile 2200K | 190lm, Vf=3V, 700mA, CRI 80, lens N | Grey | ||
GIZ22-CCL-2 | Gizmo CC/700mA LED profile 2200K | 190lm, Vf=3V, 700mA, CRI 80, lens N | Black | ||
GIZ22-CCL-3 | Gizmo CC/700mA LED profile 2200K | 190lm, Vf=3V, 700mA, CRI 80, lens N | White | ||
GIZ27-CCL-1 | Gizmo CC/700mA LED profile 2700K | 180lm, Vf=3V, 700mA, CRI 90, lens N | Grey | ||
GIZ27-CCL-2 | Gizmo CC/700mA LED profile 2700K | 180lm, Vf=3V, 700mA, CRI 90, lens N | Black | ||
GIZ27-CCL-3 | Gizmo CC/700mA LED profile 2700K | 180lm, Vf=3V, 700mA, CRI 90, lens N | White | ||
GIZ30-CCL-1 | Gizmo CC/700mA LED profile 3000K | 190lm, Vf=3V, 700mA, CRI 90, lens N | Grey | ||
GIZ30-CCL-2 | Gizmo CC/700mA LED profile 3000K | 190lm, Vf=3V, 700mA, CRI 90, lens N | Black | ||
GIZ30-CCL-3 | Gizmo CC/700mA LED profile 3000K | 190lm, Vf=3V, 700mA, CRI 90, lens N | White | ||
GIZ40-CCL-1 | Gizmo CC/700mA LED profile 4000K | 200lm, Vf=3V, 700mA, CRI 90, lens N | Grey | ||
GIZ40-CCL-2 | Gizmo CC/700mA LED profile 4000K | 200lm, Vf=3V, 700mA, CRI 90, lens N | Black | ||
GIZ40-CCL-3 | Gizmo CC/700mA LED profile 4000K | 200lm, Vf=3V, 700mA, CRI 90, lens N | White |
Gizmo Zoom CC / LED profile
- For installation on LED profile High or Low. Max 700mA.
Light temperature | Color | Art.no | Name | Specification | Color |
---|---|---|---|---|---|
GIZZ22-CCL-1 | Gizmo Zoom CC/700mA LED profile 2200K | 190lm, Vf=3V, 700mA, CRI 80, zoom 5–30° | Grey | ||
GIZZ22-CCL-2 | Gizmo Zoom CC/700mA LED profile 2200K | 190lm, Vf=3V, 700mA, CRI 80, zoom 5–30° | Black | ||
GIZZ22-CCL-3 | Gizmo Zoom CC/700mA LED profile 2200K | 190lm, Vf=3V, 700mA, CRI 80, zoom 5–30° | White | ||
GIZZ27-CCL-1 | Gizmo Zoom CC/700mA LED profile 2700K | 180lm, Vf=3V, 700mA, CRI 90, zoom 5–30° | Grey | ||
GIZZ27-CCL-2 | Gizmo Zoom CC/700mA LED profile 2700K | 180lm, Vf=3V, 700mA, CRI 90, zoom 5–30° | Black | ||
GIZZ27-CCL-3 | Gizmo Zoom CC/700mA LED profile 2700K | 180lm, Vf=3V, 700mA, CRI 90, zoom 5–30° | White | ||
GIZZ30-CCL-1 | Gizmo Zoom CC/700mA LED profile 3000K | 190lm, Vf=3V, 700mA, CRI 90, zoom 5–30° | Grey | ||
GIZZ30-CCL-2 | Gizmo Zoom CC/700mA LED profile 3000K | 190lm, Vf=3V, 700mA, CRI 90, zoom 5–30° | Black | ||
GIZZ30-CCL-3 | Gizmo Zoom CC/700mA LED profile 3000K | 190lm, Vf=3V, 700mA, CRI 90, zoom 5–30° | White | ||
GIZZ40-CCL-1 | Gizmo Zoom CC/700mA LED profile 4000K | 200lm, Vf=3V, 700mA, CRI 90, zoom 5–30° | Grey | ||
GIZZ40-CCL-2 | Gizmo Zoom CC/700mA LED profile 4000K | 200lm, Vf=3V, 700mA, CRI 90, zoom 5–30° | Black | ||
GIZZ40-CCL-3 | Gizmo Zoom CC/700mA LED profile 4000K | 200lm, Vf=3V, 700mA, CRI 90, zoom 5–30° | White |
Gimmick CC / LED profile
- For installation on LED profile High or Low. Max 700mA.
Light temperature | Color | Art.nr | Name | Specification | Color |
---|---|---|---|---|---|
GIM27-CCL-1 | Gimmick CC/350mA LED profile 2700K | 90lm, Vf=3V, CRI 90, lens W | Grey | ||
GIM27-CCL-2 | Gimmick CC/350mA LED profile 2700K | 90lm, Vf=3V, CRI 90, lens W | Black | ||
GIM30-CCL-1 | Gimmick CC/350mA LED profile 3000K | 100lm, Vf=3V, CRI 90, lens W | Grey | ||
GIM30-CCL-2 | Gimmick CC/350mA LED profile 3000K | 100lm, Vf=3V, CRI 90, lens W | Black | ||
GIM40-CCL-1 | Gimmick CC/350mA LED profile 4000K | 100lm, Vf=3V, CRI 90, lens W | Grey | ||
GIM40-CCL-2 | Gimmick CC/350mA LED profile 4000K | 100lm, Vf=3V, CRI 90, lens W | Black |
Dinkey CC 250lm / LED Profile
- Without driver. For installation of LED profile High or Low. Max 1050 mA.
Light temperature | Color | Art.no | Name | Specification | Colour |
---|---|---|---|---|---|
DIN27-CCL-1 | Dinkey CC/1050mA LED Profile 2700K | 250lm, Vf=3V, 1050mA, CRI 90, Lens N | Grey | ||
DIN27-CCL-2 | Dinkey CC/1050mA LED Profile 2700K | 250lm, Vf=3V, 1050mA, CRI 90, Lens N | Black | ||
DIN27-CCL-3 | Dinkey CC/1050mA LED Profile 2700K | 250lm, Vf=3V, 1050mA, CRI 90, Lens N | White | ||
DIN30-CCL-1 | Dinkey CC/1050mA LED Profile 3000K | 250lm, Vf=3V, 1050mA, CRI 90, Lens N | Grey | ||
DIN30-CCL-2 | Dinkey CC/1050mA LED Profile 3000K | 250lm, Vf=3V, 1050mA, CRI 90, Lens N | Black | ||
DIN30-CCL-3 | Dinkey CC/1050mA LED Profile 3000K | 250lm, Vf=3V, 1050mA, CRI 90, Lens N | White | ||
DIN40-CCL-1 | Dinkey CC/1050mA LED Profile 4000K | 250lm, Vf=3V, 1050mA, CRI 90, Lens N | Grey | ||
DIN40-CCL-2 | Dinkey CC/1050mA LED Profile 4000K | 250lm, Vf=3V, 1050mA, CRI 90, Lens N | Black | ||
DIN40-CCL-3 | Dinkey CC/1050mA LED Profile 4000K | 250lm, Vf=3V, 1050mA, CRI 90, Lens N | White |
Dinkey CC 450lm / LED Profile
- Without driver. For installation of LED profile High or Low. Max 500 mA.
Light temperature | Color | Art.no | Name | Specification | Colour |
---|---|---|---|---|---|
DIN27B-CCL-1 | Dinkey CC/500mA LED Profile 2700K | 250lm, Vf=12V, 500mA, CRI 90, Lens N | Grey | ||
DIN27B-CCL-2 | Dinkey CC/500mA LED Profile 2700K | 250lm, Vf=12V, 500mA, CRI 90, Lens N | Black | ||
DIN27B-CCL-3 | Dinkey CC/500mA LED Profile 2700K | 250lm, Vf=12V, 500mA, CRI 90, Lens N | White | ||
DIN30B-CCL-1 | Dinkey CC/500mA LED Profile 3000K | 250lm, Vf=12V, 500mA, CRI 90, Lens N | Grey | ||
DIN30B-CCL-2 | Dinkey CC/500mA LED Profile 3000K | 250lm, Vf=12V, 500mA, CRI 90, Lens N | Black | ||
DIN30B-CCL-3 | Dinkey CC/500mA LED Profile 3000K | 250lm, Vf=12V, 500mA, CRI 90, Lens N | White |
Arty Accent / CC 250 lm, LED Profile
- For installation on LED profile High or Low. Dimming via external driver.
Light temperature | Color | Art.no | Name | Specification | |
---|---|---|---|---|---|
ARTACC27-CCL-1 | Arty Accent CC/1200mA LED-profil 2700K | 250lm, CRI 90, Vf=3V, 1200mA, lens N | Grey | ||
ARTACC27-CCL-2 | Arty Accent CC/1200mA LED-profil 2700K | 250lm, CRI 90, Vf=3V, 1200mA, lens N | Black | ||
ARTACC27-CCL-3 | Arty Accent CC/1200mA LED-profil 2700K | 250lm, CRI 90, Vf=3V, 1200mA, lens N | White | ||
ARTACC30-CCL-1 | Arty Accent CC/1200mA LED-profil 3000K | 260lm, CRI 90, Vf=3V, 1200mA, lens N | Grey | ||
ARTACC30-CCL-2 | Arty Accent CC/1200mA LED-profil 3000K | 260lm, CRI 90, Vf=3V, 1200mA, lens N | Black | ||
ARTACC30-CCL-3 | Arty Accent CC/1200mA LED-profil 3000K | 260lm, CRI 90, Vf=3V, 1200mA, lens N | White |
Arty Accent / CC 450 lm, LED Profile
- For installation on LED profile High or Low. Dimming via external driver.
Light temperature | Color | Art.no | Name | Specification | |
---|---|---|---|---|---|
ARTACC27B-CCL-1 | Arty Accent CC/500mA LED-profile 2700K | 420lm, CRI 90, Vf=12V, 500mA, lens N | Grey | ||
ARTACC27B-CCL-2 | Arty Accent CC/500mA LED-profile 2700K | 420lm, CRI 90, Vf=12V, 500mA, lens N | Black | ||
ARTACC27B-CCL-3 | Arty Accent CC/500mA LED-profile 2700K | 420lm, CRI 90, Vf=12V, 500mA, lens N | White | ||
ARTACC30B-CCL-1 | Arty Accent CC/500mA LED-profile 3000K | 450lm, CRI 90, Vf=12V, 500mA, lens N | Grey | ||
ARTACC30B-CCL-2 | Arty Accent CC/500mA LED-profile 3000K | 450lm, CRI 90, Vf=12V, 500mA, lens N | Black | ||
ARTACC30B-CCL-3 | Arty Accent CC/500mA LED-profile 3000K | 450lm, CRI 90, Vf=12V, 500mA, lens N | White | ||
ARTACC27D-CCL-1 | Arty Accent CC/1000mA LED-profile 2700K | 420lm, CRI 90, Vf=6V, 1000mA, lens N | Grey | ||
ARTACC27D-CCL-2 | Arty Accent CC/1000mA LED-profile 2700K | 420lm, CRI 90, Vf=6V, 1000mA, lens N | Black | ||
ARTACC27D-CCL-3 | Arty Accent CC/1000mA LED-profile 2700K | 420lm, CRI 90, Vf=6V, 1000mA, lens N | White | ||
ARTACC30D-CCL-1 | Arty Accent CC/1000mA LED-profile 3000K | 450lm, CRI 90, Vf=6V, 1000mA, lins N | Grey | ||
ARTACC30D-CCL-2 | Arty Accent CC/1000mA LED-profile 3000K | 450lm, CRI 90, Vf=6V, 1000mA, lins N | Black | ||
ARTACC30D-CCL-3 | Arty Accent CC/1000mA LED-profile 3000K | 450lm, CRI 90, Vf=6V, 1000mA, lins N | White |
Arty Zoom / CC 250 LM LED Profile
- For installation on LED profile High or Low. Dimming via external driver.
Light temperature | Color | Art.no | Name | Specification | |
---|---|---|---|---|---|
ARTZ27-CCL-1 | Arty Zoom CC/1200mA LED-profil 2700K | CRI 90, Vf=3V, 1200mA, zoom 7-45° | Grey | ||
ARTZ27-CCL-2 | Arty Zoom CC/1200mA LED-profil 2700K | CRI 90, Vf=3V, 1200mA, zoom 7-45° | Black | ||
ARTZ27-CCL-3 | Arty Zoom CC/1200mA LED-profil 2700K | CRI 90, Vf=3V, 1200mA, zoom 7-45° | White | ||
ARTZ30-CCL-1 | Arty Zoom CC/1200mA LED-profil 3000K | CRI 90, Vf=3V, 1200mA, zoom 7-45° | Grey | ||
ARTZ30-CCL-2 | Arty Zoom CC/1200mA LED-profil 3000K | CRI 90, Vf=3V, 1200mA, zoom 7-45° | Black | ||
ARTZ30-CCL-3 | Arty Zoom CC/1200mA LED-profil 3000K | CRI 90, Vf=3V, 1200mA, zoom 7-45° | White |
Arty Zoom / CC 450 LM LED Profile
- For installation on LED Profile High or Low. Dimming via external driver.
Light temperature | Color | Art.no | Name | Specification | |
---|---|---|---|---|---|
ARTZ27B-CCL-1 | Arty Zoom CC/500mA LED-profile 2700K | CRI 90, Vf=12V, 500mA, zoom 7-45° | Grey | ||
ARTZ27B-CCL-2 | Arty Zoom CC/500mA LED-profile 2700K | CRI 90, Vf=12V, 500mA, zoom 7-45° | Black | ||
ARTZ27B-CCL-3 | Arty Zoom CC/500mA LED-profile 2700K | CRI 90, Vf=12V, 500mA, zoom 7-45° | White | ||
ARTZ27D-CCL-1 | Arty Zoom CC/1000mA LED-profile 2700K | CRI 90, Vf=6V, 1000mA, zoom 7-45° | Grey | ||
ARTZ27D-CCL-2 | Arty Zoom CC/1000mA LED-profile 2700K | CRI 90, Vf=6V, 1000mA, zoom 7-45° | Black | ||
ARTZ27D-CCL-3 | Arty Zoom CC/1000mA LED-profile 2700K | CRI 90, Vf=6V, 1000mA, zoom 7-45° | White | ||
ARTZ30B-CCL-1 | Arty Zoom CC/500mA LED-profile 3000K | CRI 90, Vf=12V, 500mA, zoom 7-45° | Grey | ||
ARTZ30B-CCL-2 | Arty Zoom CC/500mA LED-profile 3000K | CRI 90, Vf=12V, 500mA, zoom 7-45° | Black | ||
ARTZ30B-CCL-3 | Arty Zoom CC/500mA LED-profile 3000K | CRI 90, Vf=12V, 500mA, zoom 7-45° | White | ||
ARTZ30D-CCL-1 | Arty Zoom CC/1000mA LED-profile 3000K | CRI 90, Vf=6V, 1000mA, zoom 7-45° | Grey | ||
ARTZ30D-CCL-2 | Arty Zoom CC/1000mA LED-profile 3000K | CRI 90, Vf=6V, 1000mA, zoom 7-45° | Black | ||
ARTZ30D-CCL-3 | Arty Zoom CC/1000mA LED-profile 3000K | CRI 90, Vf=6V, 1000mA, zoom 7-45° | White |
Arty Framer / CC 450 LM LED Profile
- For installation on LED Profile High or Low. Dimming via external driver.
Light temperature | Color | Art.no | Name | Specification | Color |
---|---|---|---|---|---|
ARTF27B-CCL-1 | Arty Framer CC/500mA LED-Framer 2700K | 420lm, CRI 90, Vf=12V, 500mA, 25-50° | Grey | ||
ARTF27B-CCL-2 | Arty Framer CC/500mA LED-Framer 2700K | 420lm, CRI 90, Vf=12V, 500mA, 25-50° | Black | ||
ARTF27B-CCL-3 | Arty Framer CC/500mA LED-Framer 2700K | 420lm, CRI 90, Vf=12V, 500mA, 25-50° | White | ||
ARTF30B-CCL-1 | Arty Framer CC/500mA LED-Framer 3000K | 450lm, CRI 90, Vf=12V, 500mA, 25-50° | Grey | ||
ARTF30B-CCL-2 | Arty Framer CC/500mA LED-Framer 3000K | 450lm, CRI 90, Vf=12V, 500mA, 25-50° | Black | ||
ARTF30B-CCL-3 | Arty Framer CC/500mA LED-Framer 3000K | 450lm, CRI 90, Vf=12V, 500mA, 25-50° | White | ||
ARTF27D-CCL-1 | Arty Framer CC/1000mA LED-Framer 2700K | 420lm, CRI 90, Vf=6V, 1000mA, 25-50° | Grey | ||
ARTF27D-CCL-2 | Arty Framer CC/1000mA LED-Framer 2700K | 420lm, CRI 90, Vf=6V, 1000mA, 25-50° | Black | ||
ARTF27D-CCL-3 | Arty Framer CC/1000mA LED-Framer 2700K | 420lm, CRI 90, Vf=6V, 1000mA, 25-50° | White | ||
ARTF30D-CCL-1 | Arty Framer CC/1000mA LED-Framer 3000K | 450lm, CRI 90, Vf=6V, 1000mA, 25-50° | Grey | ||
ARTF30D-CCL-2 | Arty Framer CC/1000mA LED-Framer 3000K | 450lm, CRI 90, Vf=6V, 1000mA, 25-50° | Black | ||
ARTF30D-CCL-3 | Arty Framer CC/1000mA LED-Framer 3000K | 450lm, CRI 90, Vf=6V, 1000mA, 25-50° | White |
